1855610000 | Weidmüller
Disconnect/test-disconnect terminal block, screw connection, 0.5-4.0 mm², 24 A, 6 kV, dark beige, 1855610000
Unit Price (€ / pc.)
3.0702 € *
Available: 95 pcs.
Leadtime: 4 Weeks **
Test-disconnect terminal, 1855610000, Weidmüller
Disconnect and test-disconnect terminal block, screw connection, 2.5 mm², 500 V, 24 A, swivel type, cross disconnection: none, integrated test socket: No, TS 35.
The test disconnect terminal block is used to disconnect circuits for test and measurement purposes.
Technical specifications
| Connection | Schraubanschluss | |
| Number of terminals | 2 | |
| Version | Trenn-/Messtrenn Reihenklemme | |
| AWG cross-section | AWG 30 bis 12 | |
| Rated Voltage | 500 V | |
| Rated surge voltage | 6 kV | |
| Width | 5.1 mm | |
| Colour | dunkelbeige | |
| Height | 60 mm | |
| Length | 48 mm | |
| Cable cross-section | 0,5-4,0 mm² | |
| Rated current | 24 A | |
| Degree of soiling | 3 |
Download
Logistics
| Country of origin | RO |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
