1.69.525.271/1000 | RAFI
LED signal light, 24 V (DC), white, 400 mcd, Mounting Ø 10 mm, LED number: 1
LED signal lamps, type RAFI 1.69.525.
With flat round lens and integrated shunt resistor; Panel-mount diameter: 10 mm. Mounting: press-fit into the mounting cut-out. Connections: solderable tab terminals 2.8 x 0.8 mm. Operating Voltage: 24 V to 28 V. On-state current: 15 to 20 mA (red), 13 to 18.5 mA (green and yellow). Degree of protection (at the front): IP 40.
Technical attributes (type, LED/lens color, with/without suppressor diode): 1.69.525.271/1000, white, with suppressor diode
Connection | faston plug 2.8 x 0.8 mm | |
Number of LEDs | 1 | |
Diode Diameter | 12.5 mm | |
Installation diameter | 10 mm | |
Farbe der Beleuchtung | white | |
Luminous intensity | 0.4 cd | |
Assembly | snap-in | |
Rated voltage (DC) | 24 V | |
Rated current | 20 mA |
Country of origin | HU |
Customs tariff number | 85414100 |
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
